General |
Dimensions • Height: 215 mm (8.46″) • Width: 263 mm (10.35″) • Depth: 208 mm (8.18″)
Weight • 1780 g (62.78 oz)
Color • Black
Enclosure • ABS Plastic
Model Number • CP-DX650-K9=
Condition • Brand New |
|
|
|
|
Ergonomic Design |
• Touch-based phone application provides intuitive arrangement of lines, features and calls • End Call, Transfer, Conference, and Hold appear on dedicated hard keys |
|
|
|
|
Display |
• The display measures 7.00 in. (17.78 cm) diagonally; 6.05 in. (15.36 cm) horizontally; and 3.43 in. (9.00 cm) vertically
• Capacitive touchscreen includes support for various multitouch gesture commands to interact with contacts, collaboration applications, voice and video calling, and third-party applications
• High-resolution Widescreen Super Video Graphics Array (WSVGA) has 1024 x 600 pixel effective resolution. It offers backlit Light-Emitting Diodes (LEDs), it is tilt-adjustable (up to 25-degree range), and it has a Thin-Film-Transistor (TFT) Liquid Crystal Display (LCD)
• The display has 24-bit color depth (up to 16.7M colors using 6-bit + High Frame Rate Control [FRC])
• The display supports localization requiring double-byte Unicode encoding for fonts
• The display tilts back 25 degrees and forward 5 degrees from the perpendicular position in the desktop configuration |
|
|
|
|
Audio |
• The DX650 supports enhanced wideband audio (using the G.722 or iSAC codecs) through the handset, headset and speakerphone; it is TIA-920-compliant
• The speakerphone is capable of integrated full-duplex wideband audio
• The 0.14-in. (3.5-mm) stereo headset jack also supports optional headphones or external speakers |
|
|
|
|
Handset |
• The handset is a standard wideband-capable audio handset (connects through an RJ-9 port)
• The standard coiled cord has a custom end for concealed cable routing beneath the phone (cord length isapproximately 21-in. [55-cm] coiled and up to 72-in. (183-cm) extended)
• The handset is hearing aid-compatible (HAC) and meets Federal Communications Commission (FCC) loudness requirements fo r the Americans with Disabilities Act (ADA). Section 508 loudness requirements can be achieved using industry-standard inline handset amplifiers such as Walker Equipment W-10 or CE-100 amplifiers. The dial pad is also ADA-compliant |
|
|
|
|
Front Camera |
• The camera offers HD video communication with Cisco TelePresence System interoperability and other H.264 and AVC video endpoint interoperation for immersive video communication
• The integrated HD-capable front camera supports up to 1080p 30-fps video encoding and decoding
• With an integrated privacy screen slide switch, you can mechanically disable video transmission
• A dedicated LED indicator shows video status
• The field of view is 75.0 degrees diagonally and 67.4 degrees horizontally |
|
|
|
|
Operating System |
• Android OS 4.1.1 (Jelly Bean with SE Android Enforcement) |
|
|
|
|
Processor |
• TI OMAP 4460 1.5-GHz dual-core ARM Cortex-A9 |
|
|
|
|
Storage |
• 8 GB eMMC NAND Flash memory (embedded multimedia card; nonvolatile) |
|
|
|
|
Memory |
• 2 GB RAM; Low Power Double Data Rate Synchronous Dynamic Random-Access Memory (LPDDR2 SDRAM) |
|
|
|
|
Ports & Slots |
• High-Definition Multimedia Interface (HDMI) type A port
• HDMI port Dual Independent Display: Permits content from a different application to be displayed on an optional, customer-supplied LCD monitor from that presented on the DX600 Series display; an alternative “mirrored mode” enables the DX600 Series display content to be pushed out to an adjacent LCD monitor
• 3.5 mm stereo line in/out jack (for optional external headset, speakers, or headphones)
• High-speed USB 2.0 ports: - Two standard type A ports (for keyboard, mouse, external camera, thumb drive and memory stick, and headset connectivity) - One Micro-B USB port (allows connection to another device [for example, PC] for file transfer) - Maximum of 500 mA power output at 5 V or 2.5 W (depending on power budget) total across all USB ports
• Micro Secure Digital Standard Capacity (HDSC) slot for nonvolatile storage of applications or file expansion up to 32 GB (standard-definition [SD] card speed Class 4 or later recommended)
• Auxiliary port (reserved for future use) |
|
|
|
|
Physical Buttons |
• 12-key dial pad • Conference • Transfer • Hold • End Call • Volume Up/Down bar • Audio mute (with LED status indicator) • Stop video (with LED status indicator) • Speakerphone (with LED status indicator) • Headset (with LED status indicator) • Power/Lock button (with LED status indicator) |
|
|
|
|
Visual Indicator |
• Visual alert (LED) for incoming call and message-waiting indicator (MWI) on handset or cradle • Camera status LED indicator • Cisco EnergyWise Sleep Indicator on Lock button |
|
|
|
|
Power |
• IEEE 802.3af (Class 3) or IEEE 802.3at (Class 4) Power over Ethernet (PoE) standards are supported
• The DX650 is compatible with both Cisco Discovery Protocol and Link Layer Discovery Protocol-Media Endpoint Discovery (LLDP-MED) PoE switch blades
• Power budget: 13.7W (Cisco Discovery Protocol) or 15.1W (LLDP) for 802.3AF and low-power USB peripheral support; greater than 15.4W and 802.3AT required for high-power USB peripheral support |
|
|
|
|
Physical Security |
• Compatible with Kensington Security Slot (K-Slot) anti-theft system (can accommodate a lock up to 20 mm wide)
• Optional wall-mount bracket (lockable) |
|
|
|
|
Ethernet |
• Internal 2-port Cisco Ethernet switch allows for a direct connection to a 10/100/1000BASE-T Ethernet network (IEEE 802.3i/802.3u/802.3ab) through an RJ-45 interface with single LAN connectivity for both the phone and a co-located PC
• The system administrator can designate separate VLANs (IEEE 802.1Q) for the PC and phone, providing improved security and reliability of voice and data traffic |
|
|
|
|
Desktop Wi-Fi |
• As an alternative to wired Ethernet, the DX650 supports a Wi-Fi radio with integrated antenna enabling connectivity to a Wi-Fi access-point infrastructure, thereby saving on the labor costs of pulling Ethernet cables to every work location |
|
|
|
|
Network Features |
• Cisco Discovery Protocol • Cisco Peer-to-Peer Distribution Protocol (PPDP) • LLDP-MED • Session Initiation Protocol (SIP) for signaling • Session Description Protocol (SDP) • User Datagram Protocol (UDP) (used only for Real-Time Transport Protocol [RTP] streams) • Dynamic Host Configuration Protocol (DHCP) client or static configuration • Transparent secure roaming • Gratuitous Address Resolution Protocol (GARP) • Switch auto-negotiation • Domain Name System (DNS) • Web proxy (configured manually or by auto-configuration Protected Access Credential [PAC] files) • NT LAN Manager (NTLM) and Kerberos authentication • Trivial File Transfer Protocol (TFTP) • Secure Hypertext Transfer Protocol (HTTPS) • Wi-Fi management • IPv4 configuration • IPv6 configuration • Virtual Local Area Network (VLAN) • Real-Time Control Protocol (RTCP) (provides quality of service [QoS] data [such as jitter, latency, and round-trip delay] on RTP streams in order to provide a better video experience) • Secure Real-Time Transport Protocol (SRTP) • Software port speed (manual or auto-configuration, including disablement) • PC port speed (manual or auto-configuration, including disablement) • Telepresence Interoperability Protocol (TIP) • Binary Floor Control Protocol (BFCP) |
|
|
|
|
Bluetooth |
• Bluetooth 3.0 Enhanced Data Rate (EDR) Class 2 technology (up to 30-ft [10m] range)
• Human Interface Device (HID) keyboard and mouse support for adding additional input accessories
• Hands-Free Profile (HFP) for untethered headset connections and voice communications
• Phone Book Access Profile (PBAP), which enables the exchange of phone book objects between devices
• Advanced Audio Distribution Profile (A2DP) for streaming audio
• Object Push Profile (OPP) for generic file exchange |
|
|
|
|
Firmware |
Call-platform support, provisioning & management • Cisco UCM Version 8.6.2 or later • Backward compatibility with Cisco UCM Versions 7.1.5 and 8.5.1 (no support for Android package [APK] provisioning in 7.1.5) • Cisco Hosted Collaboration Solution (HCS) Version 8.6.2 or later • Cisco Business Edition 6000 Version 9.1 or later
Upgrading Process • Software upgrade of the device through Cisco UCM • Support for online firmware upgrades using TFTP • HTTP firmware management
|
|
|
|
|
Temperature Range |
Operating Temperature • 32° F to 104° F (0° C to 40° C)
Relative Humidity • 10 to 95% (noncondensing)
Storage Temperature • 14° F to 140° F (-10° C to 60° C)
|
|
|
|
|
In the Box |
• 1 x Cisco DX650 Video IP Phone • 1 x Handset • 1 x Handset Cord Cable • 1 x Stand • 1 x Ethernet Cord Cable
|
